Victron MultiPlus-II 48/4k5/55-32 230V
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Victron MultiPlus-II 48/4k5/55-32 230V (PMP482405012) is a multifunctional inverter/charger for professional marine, vehicle, off-grid and ESS installations on a 48 V battery bank. Victron rates continuous inverter output at 4 kW at 25°C, with a 4.5 kW cold-start capability (2 hours); the integrated charger delivers up to 55 A and the transfer switch is 32 A.
PowerControl and PowerAssist manage limited shore or generator supplies, and changeover to inverter operation is typically under 20 milliseconds. The unit is ESS-ready with anti-islanding, and supports parallel and three-phase expansion. An optional external AC current sensor extends PowerControl/PowerAssist. Configuration is via VEConfigure/MK3-USB; a GX device adds local and VRM remote monitoring.
Do not confuse this SKU with the MultiPlus-II 48/5000/70-50 (PMP482505012), which is a different 5000 VA / 70 A / 50 A model.
PRODUCT DETAILS
- About 4 kW continuous inverter output at 25°C (4.5 kW cold-start class) at 230 VAC for 48 V battery banks
- 55 A multi-stage battery charger
- 32 A AC transfer switch with PowerControl and PowerAssist
- PowerAssist boosts limited shore or generator supply with battery power to avoid overload
- Uninterrupted transfer to inverter typically under 20 milliseconds during a power failure
- ESS-ready with built-in anti-islanding
- Parallel and three-phase capable for higher output
- Monitoring and configuration via VEConfigure, GX devices and the free VRM portal
No exploded diagram available for this product.
No compatible transducers listed for this product.
No compatible products found.
Key specifications
| System voltage | 48 V |
| Continuous output power | 4500 VA |
| Continuous output power at 25°C | 4000 W |
| Peak power | 7000 W |
| Maximum charge current | 55 A |
| Transfer switch | 32 A |
AC inputs
| AC input voltage range | 187 to 265 VAC |
| AC input frequency | 45 to 65 Hz |
| Maximum feed-through current | 32 A |
Inverter
| DC input voltage range | 38 to 60 V |
| Output voltage / frequency | 230 VAC ±2%, 50 Hz ±0.1% |
| Cont. output power at 25°C (VA) | 4500 VA |
| Cont. output power at 25°C (W) | 4000 W |
| Cont. output power at 40°C (W) | 3700 W |
| Cont. output power at 65°C (W) | 3000 W |
| Peak power | 7000 W |
| Maximum efficiency | 95% |
| Maximum apparent feed-in power | 4000 W |
| Zero load power | 20 W |
| Zero load power in Search mode | 8 W |
| Zero load power in AES mode | 13 W |
Charger
| Charge voltage 'absorption' | 57.6 V |
| Charge voltage 'float' | 55.2 V |
| Storage mode | 52.8 V |
| Maximum charge current | 55 A |
| Battery temperature sensor | Not included with 48 V models (order ASS000001000) |
Connectivity & control
| VE.Bus communication port | For parallel and three-phase operation, remote monitoring and system integration |
| General purpose comms port | Yes, 2x |
| Programmable relay | Yes |
| Auxiliary output | 32 A |
| Remote on/off | Yes |
| External AC current sensor (optional) | 100 A |
Protection
| Protection | Output short circuit, overload, battery voltage too high, battery voltage too low, temperature too high, 230 VAC on inverter output, input voltage ripple too high |
Environmental
| Operating temperature range | -40 to +65°C (fan-assisted cooling) |
| Humidity (non-condensing) | Max 95% |
| Maximum altitude | 2000 m |
Physical
| Material & colour | Steel, blue RAL 5012 |
| Protection category | IP21 |
| Battery connection | M8 bolts |
| 230 VAC connection | Screw terminals 13 mm² (6 AWG) |
| Weight | 22 kg |
| Dimensions (h x w x d) | 590 x 275 x 149 mm |
Conformance
| Safety | EN-IEC 60335-1, EN-IEC 60335-2-29, EN-IEC 62109-1, EN-IEC 62109-2 |
| Emission / Immunity | EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, IEC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3 |
