Scanstrut Horizontal Marine Cable Seals & Glands
Horizontal cable entry glands designed for side-entry applications on marine electronics and electrical installations. Our Horizontal collection features:
- Horizontal Entry Glands - Side-entry cable management for clean installations
- Waterproof Seals - IP66/IPX6-rated protection from the side
- Space-Efficient Design - Minimal protrusion from mounting surface
- Marine-Grade Construction - UV-resistant materials with stainless hardware
Horizontal cable glands are perfect for bulkhead penetrations, side-entry junction boxes, and applications where vertical space is limited. Provides secure strain relief and waterproof protection with a professional finish.
Alternative Cable Entries: Compare with Vertical cable glands for top-entry applications. Use with Through Bulkhead, Waterproof, Multi-cable, and Low Profile glands. Perfect for MarinePod and Scanpod installations. More Scanstrut solutions.
Fitting a horizontal cable gland
A horizontal gland is chosen over a vertical one mainly for clearance, since it enters the panel from the side rather than needing headroom above and below the cutout, which suits tight consoles, pod bases and bulkheads where a vertical gland simply will not fit. Check the gland's cable diameter range against the actual cable or bundle passing through it, including the connector if it is being fed through assembled, since many glands only accept a bare cable end and need connectors fitted afterwards.
Drill the mounting hole to the size specified for that gland rather than judging it by eye, as an oversized hole compromises the seal even with a compliant cable, and always fit the supplied gasket rather than relying on sealant alone. Where more than one cable needs to pass through the same point, a multi-cable gland avoids drilling several separate holes and keeps the bulkhead or pod base stronger.
