Lopolight NL201-003-FB-REVERSE 2nm Combined Sidelight, Upside-down with FB Base

£490.76
Tax included. Shipping calculated at checkout.
NL201-003-FB-REVERSE
Lopolight 2nm Combined Sidelight, Upside-down with FB Base (NL201-003-FB-REVERSE): LED navigation light, 2 nm visibility, 10-32 VDC, IP68.

Pickup available at Mercury Yacht Harbour

Usually ready in 2-4 days

Description

The Lopolight 2nm Combined Sidelight, Upside-down with FB Base (part number NL201-003-FB-REVERSE) is an LED navigation light from Lopolight of Denmark.

Key points: 2 nm visibility. It operates from 10-32 VDC and draws 2.2 W. Lopolight lists it as IP68 rated, operating temperature -25°C to 55°C, horizontal mounting. Approved to COLREG72, EN14744, IEC 60945, IACS E10, USCG, ABS, M.E.D., DNV, LR (per Lopolight). Lopolight lists this part for vessel sizes: 12-20M.

Supplied with: 1 Navigation light, precabled with 2.5 meter shielded marine grade cable, Installation guide.

PRODUCT DETAILS

  • 2 nm visibility
  • 10-32 VDC operating voltage
  • IP68 protection
  • Approvals: COLREG72, EN14744, IEC 60945, IACS E10, USCG, ABS, M.E.D., DNV, LR
  • Horizontal mounting
  • Connection: 2.5m cable
  • 1 Navigation light, precabled with 2.5 meter shielded marine grade cable, Installation guide

No exploded diagram available for this product.

No compatible transducers listed for this product.

No spares or accessories listed for this product.

No compatible products found.

Performance

Visibility2nm
Visibility2nm

Electrical

Operating voltage10-32VDC
Operating voltage10-32VDC
Power draw (W)2.2
Power draw (W)2.2
Current consumption @ 12 VDC163 mA
Current consumption @ 12 VDC163 mA
Current consumption @ 24 VDC90 mA
Current consumption @ 24 VDC90 mA
Minimum feed wire gauge0.5mm2 AWG22
Minimum feed wire gauge0.5mm2 AWG22

Mechanical

MountingHorizontal
MountingHorizontal
DimensionsØ92,5mm x 36mm
DimensionsØ92,5mm x 36mm
Connection2.5m cable
Connection2.5m cable
MaterialsSilver anodized aluminum 25µ, PMMA lens, A4 stainless steel screws, Epoxy, Polyurethane
MaterialsSilver anodized aluminum 25µ, PMMA lens, A4 stainless steel screws, Epoxy, Polyurethane
Weight0.55 kg
Weight0.55 kg

Environmental

IP ratingIP68
IP ratingIP68
Operating temperature-25°C to 55°C
Operating temperature-25°C to 55°C

Approvals

Approved toCOLREG72,EN14744,IEC 60945,IACS E10,USCG,ABS,M.E.D.,DNV,LR
Approved toCOLREG72,EN14744,IEC 60945,IACS E10,USCG,ABS,M.E.D.,DNV,LR

General

Vessel size (Lopolight range)12-20M
Vessel size (Lopolight range)12-20M
Lopolight part number201-003-FB-REVERSE
Lopolight part number201-003-FB-REVERSE
IMP part numberNL201-003-FB-REVERSE
IMP part numberNL201-003-FB-REVERSE
UPC879343043438
UPC879343043438
EAN5704438043305
EAN5704438043305

No videos available for this product.

What is the visibility range of the Lopolight NL201-003-FB-REVERSE?
Lopolight specifies 2 nautical mile(s) visibility for this part.
What supply voltage does the Lopolight NL201-003-FB-REVERSE need?
Lopolight lists an operating voltage of 10-32 VDC with a power draw of 2.2 W.
Which approvals does the Lopolight NL201-003-FB-REVERSE carry?
Lopolight lists approvals to COLREG72, EN14744, IEC 60945, IACS E10, USCG, ABS, M.E.D., DNV, LR. Declarations of conformity and certificates are published on lopolight.com under Support.
