Lopolight NL300-112G2-B-CD-180 3nm 180° White, Black Anodized (lopolight.com image) Lopolight NL300-112G2-B-CD-180 3nm 180° White, Black Anodized (lopolight.com image)
Lopolight NL300-112G2-B-CD-180 3nm 180° White, Black Anodized (lopolight.com image)

Lopolight

Lopolight NL300-112G2-B-CD-180 3nm 180° White, Black Anodized

£1,126.60
Tax included. Shipping calculated at checkout.
NL300-112G2-B-CD-180
Lopolight 3nm 180° White, Black Anodized (NL300-112G2-B-CD-180): LED navigation light, 3 nm visibility, 10-32 VDC, IP68.

Pickup available at Mercury Yacht Harbour

Usually ready in 2-4 days

Description

The Lopolight 3nm 180° White, Black Anodized (part number NL300-112G2-B-CD-180) is an LED navigation light from Lopolight of Denmark.

Key points: 3 nm visibility, 180° light arc, white light. It operates from 10-32 VDC and draws 2.9 W. Lopolight lists it as IP68 rated, operating temperature -25°C to 55°C, horizontal mounting. Approved to COLREG72, EN14744, IEC 60945, IACS E10, USCG, ABS, M.E.D., DNV, LR (per Lopolight).

Supplied with: 1 Navigation light.

PRODUCT DETAILS

  • 3 nm visibility
  • 180° light arc
  • 10-32 VDC operating voltage
  • IP68 protection
  • Approvals: COLREG72, EN14744, IEC 60945, IACS E10, USCG, ABS, M.E.D., DNV, LR
  • Horizontal mounting
  • Connection: Plug connector
  • 1 Navigation light

No exploded diagram available for this product.

No compatible transducers listed for this product.

No spares or accessories listed for this product.

No compatible products found.

Performance

Visibility3nm
Visibility3nm
Light arc180°
Light arc180°
Light colourWhite
Light colourWhite

Electrical

Operating voltage10-32VDC
Operating voltage10-32VDC
Power draw (W)2.9
Power draw (W)2.9
Current consumption @ 12 VDC22 mA
Current consumption @ 12 VDC22 mA
Current consumption @ 24 VDC157 mA
Current consumption @ 24 VDC157 mA

Mechanical

MountingHorizontal
MountingHorizontal
DimensionsØ92,5mm x 89,5mm
DimensionsØ92,5mm x 89,5mm
ConnectionPlug connector
ConnectionPlug connector
MaterialsBlack anodized aluminum 25µ, PMMA lens, A4 stainless steel screws, Epoxy, Polyurethane
MaterialsBlack anodized aluminum 25µ, PMMA lens, A4 stainless steel screws, Epoxy, Polyurethane
Housing finishBlack anodized
Housing finishBlack anodized
Weight0.97 kg
Weight0.97 kg

Environmental

IP ratingIP68
IP ratingIP68
Operating temperature-25°C to 55°C
Operating temperature-25°C to 55°C

Approvals

Approved toCOLREG72,EN14744,IEC 60945,IACS E10,USCG,ABS,M.E.D.,DNV,LR
Approved toCOLREG72,EN14744,IEC 60945,IACS E10,USCG,ABS,M.E.D.,DNV,LR

General

Lopolight part number300-112G2-B-CD-180
Lopolight part number300-112G2-B-CD-180
IMP part numberNL300-112G2-B-CD-180
IMP part numberNL300-112G2-B-CD-180
UPC879343038021
UPC879343038021
EAN5704438037892
EAN5704438037892

No videos available for this product.

No downloads available for this product.

What is the visibility range of the Lopolight NL300-112G2-B-CD-180?
Lopolight specifies 3 nautical mile(s) visibility for this part.
What supply voltage does the Lopolight NL300-112G2-B-CD-180 need?
Lopolight lists an operating voltage of 10-32 VDC with a power draw of 2.9 W.
Which approvals does the Lopolight NL300-112G2-B-CD-180 carry?
Lopolight lists approvals to COLREG72, EN14744, IEC 60945, IACS E10, USCG, ABS, M.E.D., DNV, LR. Declarations of conformity and certificates are published on lopolight.com under Support.
