Lopolight NL301-001-WH 2nm Stbd, White Ceramic Coated, White Ceramic Finish, Vertically Mounted with 2.5m Cable

£324.88
Tax included. Shipping calculated at checkout.
NL301-001-WH
Lopolight 2nm Stbd, White Ceramic Coated, White Ceramic Finish, Vertically Mounted with 2.5m Cable (NL301-001-WH): LED navigation light, 2 nm visibility, 10-32 VDC, IP68.

Pickup available at Mercury Yacht Harbour

Usually ready in 2-4 days

Description

The Lopolight 2nm Stbd, White Ceramic Coated, White Ceramic Finish, Vertically Mounted with 2.5m Cable (part number NL301-001-WH) is an LED navigation light from Lopolight of Denmark.

Key points: 2 nm visibility, white light. It operates from 10-32 VDC and draws 2 W. Lopolight lists it as IP68 rated, operating temperature -25°C to 55°C, vertical mounting. Approved to COLREG72, EN14744, IEC 60945, IACS E10, USCG, ABS, M.E.D., DNV, LR (per Lopolight). Lopolight lists this part for vessel sizes: 12-20M, 20-50M.

Supplied with: 1 Navigation light, precabled with 2.5 meter shielded marine grade cable, 2 Mounting screws (M6 * 8 mm), Installation guide.

PRODUCT DETAILS

  • 2 nm visibility (>5.4cd)
  • 10-32 VDC operating voltage
  • IP68 protection
  • Approvals: COLREG72, EN14744, IEC 60945, IACS E10, USCG, ABS, M.E.D., DNV, LR
  • Vertical mounting
  • Connection: 2.5m cable
  • 1 Navigation light, precabled with 2.5 meter shielded marine grade cable, 2 Mounting screws (M6 * 8 mm), Installation guide

No exploded diagram available for this product.

No compatible transducers listed for this product.

No spares or accessories listed for this product.

No compatible products found.

Performance

Visibility2nm
Visibility2nm
Intensity>5.4cd
Intensity>5.4cd
Light colourWhite
Light colourWhite

Electrical

Operating voltage10-32VDC
Operating voltage10-32VDC
Power draw (W)2
Power draw (W)2
Current consumption @ 12 VDC110 mA
Current consumption @ 12 VDC110 mA
Current consumption @ 24 VDC60 mA
Current consumption @ 24 VDC60 mA
Minimum feed wire gauge0.5mm2 AWG22
Minimum feed wire gauge0.5mm2 AWG22

Mechanical

MountingVertical
MountingVertical
Dimensions92,5 x 28 x 49,7 mm
Dimensions92,5 x 28 x 49,7 mm
Connection2.5m cable
Connection2.5m cable
MaterialsCeramic Coated white aluminum, PMMA lens, A4 stainless steel screws, Epoxy, Polyurethane
MaterialsCeramic Coated white aluminum, PMMA lens, A4 stainless steel screws, Epoxy, Polyurethane
Weight0.31 kg
Weight0.31 kg

Environmental

IP ratingIP68
IP ratingIP68
Operating temperature-25°C to 55°C
Operating temperature-25°C to 55°C

Approvals

Approved toCOLREG72,EN14744,IEC 60945,IACS E10,USCG,ABS,M.E.D.,DNV,LR
Approved toCOLREG72,EN14744,IEC 60945,IACS E10,USCG,ABS,M.E.D.,DNV,LR

General

Vessel size (Lopolight range)12-20M,20-50M
Vessel size (Lopolight range)12-20M,20-50M
Lopolight part number301-001-WH
Lopolight part number301-001-WH
IMP part numberNL301-001-WH
IMP part numberNL301-001-WH
UPC879343039387
UPC879343039387
EAN5704438039254
EAN5704438039254

No videos available for this product.

What is the visibility range of the Lopolight NL301-001-WH?
Lopolight specifies 2 nautical mile(s) visibility with intensity >5.4cd for this part.
What supply voltage does the Lopolight NL301-001-WH need?
Lopolight lists an operating voltage of 10-32 VDC with a power draw of 2 W.
Which approvals does the Lopolight NL301-001-WH carry?
Lopolight lists approvals to COLREG72, EN14744, IEC 60945, IACS E10, USCG, ABS, M.E.D., DNV, LR. Declarations of conformity and certificates are published on lopolight.com under Support.
