Lopolight NL301-009ST-PRO 2nm Double Port, Black Anodized

£602.94
Tax included. Shipping calculated at checkout.
NL301-009ST-PRO
Lopolight 2nm Double Port, Black Anodized (NL301-009ST-PRO): LED navigation light, 2 nm visibility, 10-32 VDC, IP68.

Pickup available at Mercury Yacht Harbour

Usually ready in 2-4 days

Description

The Lopolight 2nm Double Port, Black Anodized (part number NL301-009ST-PRO) is an LED navigation light from Lopolight of Denmark.

Key points: 2 nm visibility. It operates from 10-32 VDC and draws 1.2 W. Lopolight lists it as IP68 rated, operating temperature -25°C to 55°C, horizontal mounting. Approved to COLREG72, EN14744, IEC 60945, IACS E10, USCG, ABS, M.E.D., DNV, LR (per Lopolight). Lopolight lists this part for vessel sizes: 12-20M, 20-50M.

Supplied with: 1 Navigation light, 2 Mounting screws (M6 * 8 mm), Installation guide.

PRODUCT DETAILS

  • 2 nm visibility (>5.4cd)
  • 10-32 VDC operating voltage
  • IP68 protection
  • Approvals: COLREG72, EN14744, IEC 60945, IACS E10, USCG, ABS, M.E.D., DNV, LR
  • Horizontal mounting
  • Connection: Plug connector
  • 1 Navigation light, 2 Mounting screws (M6 * 8 mm), Installation guide

No exploded diagram available for this product.

No compatible transducers listed for this product.

No spares or accessories listed for this product.

No compatible products found.

Performance

Visibility2nm
Visibility2nm
Intensity>5.4cd
Intensity>5.4cd

Electrical

Operating voltage10-32VDC
Operating voltage10-32VDC
Power draw (W)1.2
Power draw (W)1.2
Current consumption @ 12 VDC90 mA
Current consumption @ 12 VDC90 mA
Current consumption @ 24 VDC50 mA
Current consumption @ 24 VDC50 mA
Minimum feed wire gauge0.5mm2 AWG22
Minimum feed wire gauge0.5mm2 AWG22

Mechanical

MountingHorizontal
MountingHorizontal
DimensionsØ92,5mm x 96,5mm
DimensionsØ92,5mm x 96,5mm
ConnectionPlug connector
ConnectionPlug connector
MaterialsBlack hard coat anodized aluminum 50µ, PMMA lens, A4 stainless steel screws, Epoxy, Polyurethane
MaterialsBlack hard coat anodized aluminum 50µ, PMMA lens, A4 stainless steel screws, Epoxy, Polyurethane
Housing finishBlack anodized
Housing finishBlack anodized
Weight1.41 kg
Weight1.41 kg

Environmental

IP ratingIP68
IP ratingIP68
Operating temperature-25°C to 55°C
Operating temperature-25°C to 55°C

Approvals

Approved toCOLREG72,EN14744,IEC 60945,IACS E10,USCG,ABS,M.E.D.,DNV,LR
Approved toCOLREG72,EN14744,IEC 60945,IACS E10,USCG,ABS,M.E.D.,DNV,LR

General

Vessel size (Lopolight range)12-20M,20-50M
Vessel size (Lopolight range)12-20M,20-50M
Lopolight part number301-009ST-PRO
Lopolight part number301-009ST-PRO
IMP part numberNL301-009ST-PRO
IMP part numberNL301-009ST-PRO
UPC879343013035
UPC879343013035
EAN5704438013032
EAN5704438013032

No videos available for this product.

What is the visibility range of the Lopolight NL301-009ST-PRO?
Lopolight specifies 2 nautical mile(s) visibility with intensity >5.4cd for this part.
What supply voltage does the Lopolight NL301-009ST-PRO need?
Lopolight lists an operating voltage of 10-32 VDC with a power draw of 1.2 W.
Which approvals does the Lopolight NL301-009ST-PRO carry?
Lopolight lists approvals to COLREG72, EN14744, IEC 60945, IACS E10, USCG, ABS, M.E.D., DNV, LR. Declarations of conformity and certificates are published on lopolight.com under Support.
