Glomex Mizar AGC Black TV Antenna

Manufacturer Part No: V9128AAGCBK | £172.76 ex-VAT

14X20CM DVB-T2 TV ANTENNA – AUTOMATIC GAIN AMPLIFIER – TV, DAB AND FM SIGNALS RECEPTION

MIZAR AGC is a compact omnidirectional DVB-T2 TV and DAB antenna that makes your life easier and more comfortable with the innovative automatic gain control amplifier. Moreover, in order to keep a balanced look of your boat, Mizar AGC can be matched to weBBoat 4G Lite, the integrated internet antenna system, as they are identical in shape and size. Thanks to the amplifier you have only to turn on the TV, stay comfortably seated and enjoy your favourite programs; Mizar AGC will adjust by itself the gain of the TV signal to ensure the best possible reception of television broadcasts. Mizar AGC is a very compact (diam.: 14 cm/5.5” diam, height: 20 cm/8, weight: 500 gr/1.1lb) Omni-directional TV antenna ensuring high performance in signal reception with both polarizations: horizontal and vertical. SUPPLIED ACCESSORIES:

50023/14 AMPLIFIER
20 M (66′) COAXIAL CABLE to connect the antenna with the amplifier
1,5 M (5′) SET CORD to connect the amplifier to the TV / Decoder
V9144 F-MALE GOLD PLATED CONNECTOR
FLUSH MOUNTE FOR INSTALLATION ON ROLL-BAR
THREADED TERMINATION FOR 1 “”X14 MOUNTS

ANTENNA DIAMETER	140 mm (5.5”)
ANTENNA HEIGHT	200 mm (8″)
BASE DIAMETER	1″x14
ANTENNA WEIGHT	500 g (1.1lb)
RADOME MATERIAL	U.V. resistant ASA
ANGLE OF RECEPTION	360°
POLARIZATION	Horizontal / Vertical
IMPEDANCE	75 ohms
FREQUENCY RANGE	87,5/774 MHz
GAIN AVERAGE	20 dB
NOISE FACTOR	2,2 dB
POWER CONSUMPTION	60 mA
POWER SUPPLY	12/24 Vdc
ADJUSTABLE GAIN	AUTOMATIC
TV SET MAX	2
TERMINATION	F female
CONNECTOR SUPPLIED	F male gold plated connector (V9144)
